3 Front-Panel Operation
82 Keysight E3633A and E3634A User’s Guide
To set the baud rate and parity (RS-232)
To configure the power supply for the RS-232 interface, proceed as follows:
1 Turn on the remote configuration mode.
You will see the above message on the display if the power supply has not
been changed from the factory setting.
Notice that if you changed the remote interface selection to RS-232 before,
“RS-232” message will be displayed.
2 Choose the RS-232 interface.
You can choose the RS-232 interface by turning the knob to the left.
3 Move to the RS-232 interface setting mode and select the baud rate.
The rate is set to 9600 baud when the power supply is shipped from the
factory. Choose from one of the following by turning the knob to the right or
left: 300, 600, 1200, 2400, 4800, or 9600 baud.
4 Save the change and choose the parity
The power supply is configured for 8 data bits with no parity when shipped
from the factory. Choose from one of the following by turning the knob to the
right or left: None 8 Bits, Odd 7 Bits, or Even 7 Bits. When you set parity, you
are indirectly setting the number of the data bits.
HPIB / 488
RS-232
9600 BAUD
NONE 8 BITS
To Next Page
