3 Front-Panel Operation
56 Keysight E3633A and E3634A User’s Guide
Storing and Recalling Operating States
You can store up to three different operating states in non-volatile memory. This
also enables you to recall the entire instrument configuration with just a few key
presses from the front panel.
The memory locations are supplied with the reset states from the factory for
front-panel operation. Refer to the description of “*RST” on page 126 for more
information. The following steps show you how to store and recall an operating
state.
– Front-panel operation:
1 Set up the power supply for the desired operating state.
The storage feature “remembers” output range selection, the limit value
settings of voltage and current, output on/off state, OVP and OCT on/off
state and OVP and OCP trip levels.
2Turn on the storage mode.
Three memory locations (numbered 1, 2 and 3) are available to store the
operating states. The operating states are stored in non-volatile memory
and are remembered when being recalled.
This message appears on the display for approximately 3 seconds.
3 Store the operating state in memory location “3”.
Turn the knob to the right to specify the memory location 3.
To cancel the store operation, let the display time-out after about 3
seconds or press any other function key except the ion key except the
key. The power supply returns to the normal operating mode and to the
function pressed. Save the operating state.
STORE 1
STORE 3
