Front-Panel Operation 3
Keysight E3633A and E3634A User’s Guide 65
– Adjust output current level
1 Lower the output current level.
Press key and set the knob for current control by pressing key
then lower the output current level below the OCP trip point.
2 Move to the clear mode.
Press key twice to move to the OCP CLEAR mode. The “OCP ON”
message appears on the display. Turn the knob to the right until the above
message appears on the display
3 Clear the overcurrent condition and exit this menu.
Now, when you press key again, the “DONE” message is displayed for
a second and the OCP annunciator will not blink any more. The output will
return to meter mode. The knob is selected for current control.
Notice that the power supply is operated in the constant current (CC)
mode.
OCP CLEAR
