Keysight E5071C ENA Series User Manual

Keysight E5071C ENA Series RF Network Analyzers 13
Installation
Environmental Requirements
Environmental Requirements
Set up the E5071C where the following environmental requirements are met.
Operating Environments
Ensure that the operating environment meets the following requirements.
Temperature 5˚C to 40˚C
Temperature range at the
error-correction
23˚C  5˚C (< 1˚C deviation from the temperature
when performing the error-correction)
Humidity 20% to 80% at wet bulb temperature < +29˚C
(non-condensation)
Altitude 0 to 2,000 m (0 to 6,561 feet)
Vibration 0.21 G maximum, 5 Hz to 500 Hz
Above environmental requirements are NOT for the specifications and
measurement accuracy of the analyzer, but for the operating environment
of the analyzer.

Keysight E5071C ENA Series Specifications

General

Number of Ports	2 or 4
Dynamic Range	>123 dB (typical)
Connectivity	LAN, USB, GPIB
Display	10.4-inch LCD
Trace Noise	0.004 dB rms
Impedance	50 Ohm
Weight	20 kg
Dimensions	426 mm × 177 mm × 407 mm
