Installation
Power Supply
2-
Power Supply
Before turning on the E5071C power, check the following.
Verification of the Power Supply
Confirm that the power supplied to the E5071C meets the following
requirements:
Verification and Connection of Power Cable
The three-wire power cable attached to the E5071C has one wire serving as a
ground. Using this power cable allows the E5071C to be grounded, thereby
protecting you against electrical shock from the power outlet.
Step 1. Confirm that the power cable is not damaged.
Step 2. Use the supplied cable to connect between the power cable receptacle
(Figure 2-7 on page 24) on the rear panel of the E5071C and a three-wire
power outlet with the grounding prong firmly connected in the ground slot.
Power cord information is available at
http://www.keysight.com/find/powercords.
Requirements
Voltage
90 to 132 VAC or 198 to 264 VAC
1
1. Switched automatically by the E5071C in conformity to the voltage used.
Frequency 47 to 63 Hz
Maximum power consumption 350 VA
NEVER use a power cable showing any sign of damage. Faulty cables can
cause electrical shock.
Use the supplied power cable with grounding wire to securely ground the
E5071C.

Keysight E5071C ENA Series Specifications

General

Number of Ports	2 or 4
Dynamic Range	>123 dB (typical)
Connectivity	LAN, USB, GPIB
Display	10.4-inch LCD
Trace Noise	0.004 dB rms
Impedance	50 Ohm
Weight	20 kg
Dimensions	426 mm × 177 mm × 407 mm
