Keysight E5071C ENA Series RF Network Analyzers 53
Troubleshooting
System Recovery
User Recovery (only for HDD Revision CN924 or below)
Procedure to create the user backup image (only available when HDD
Revision is CN924 or below)
This section describes how to create the user backup image. The C and D
drives’ contents saved in this procedure are recalled when the user recovery
function is executed.
Step 1. Close the E5071C application by pressing System > Service Menu > Exit.
Step 2. Close all other applications you currently open.
Step 3. From the Windows start menu, select All Programs > Acronis > Acronis True
Image.
Step 4. Click “No, Thanks” button.
Figure 3-17 Recover User Backup
e5071cse1080
