Keysight E5071C ENA Series User Manual

16 Keysight E5071C ENA Series RF Network Analyzers
Installation
Installing Front Handles/Rack Mounting Flanges
2-
Installing Front Handles/Rack Mounting Flanges
The E5071C can be installed on a workbench or in a rack. This section
describes how to install the front handles (Option 1CN) used for moving or
transporting the instrument, and how to install the analyzer in an equipment
rack as part of a measurement system (Option 1CM: without the handles,
Option 1CP: with the handles).
Table 2-1 Keysight E5071C handles/rack mounting options
Option Name
1CN Handle Kit
1CM Rack-mount Kit
1CP Rack-mount and Handle Kit
Table 2-2 Contents of each option
Option Contents Quantity
1CN Front Handles 2
Screws 6
Trim Strips 2
1CM Rack-mounting flanges (locking side plate) 2
Screws 6
1CP Rack-mounting flanges (locking side plate) 2
Front Handles 2
Screws 8

Keysight E5071C ENA Series Specifications

General

Number of Ports	2 or 4
Dynamic Range	>123 dB (typical)
Connectivity	LAN, USB, GPIB
Display	10.4-inch LCD
Trace Noise	0.004 dB rms
Impedance	50 Ohm
Weight	20 kg
Dimensions	426 mm × 177 mm × 407 mm
