C External Instrument Calibration
60 Keysight E6961A User Guide and Method of Implementation
Introduction
All instruments must be calibrated prior to running the Compliance tests. The
compliance application software guides you in calibrating the AWG and the ENA.
Calibrating the AWG
Before running disturbing signal tests, the AWG(s) must be calibrated. Connect
the equipment as shown in Figure C-1 on page 61.
The AWG Disturbing Signal Source must be Configured before attempting to
Calibrate it. If the system is not physically configured to perform the calibration,
the application prompts you to change the physical configuration. Refer to
“Appendix B: Configure External Instruments” on page 57
Instead of connecting SMA to SMA cables on the N5393C Evaluation Board,
connect 50
Terminators to the two DUT SMA Connectors on the Evaluation
Board. This is shown in Figure C-1 below
