22 Keysight InfiniiVision DSOX1204A/G Oscilloscopes User's Guide
1 Getting Started
8. Run Control
keys
When the [Run/Stop] key is green, the oscilloscope is running, that is, acquiring data when trigger
conditions are met. To stop acquiring data, press [Run/Stop].
When the [Run/Stop] key is red, data acquisition is stopped. To start acquiring data, press
[Run/Stop].
To capture and display a single acquisition (whether the oscilloscope is running or stopped), press
[Single]. The [Single] key is yellow until the oscilloscope triggers.
For more information, see "Running, Stopping, and Making Single Acquisitions (Run
Control)" on page 32.
9. Measure
controls
The measure controls consist of:
•[Analyze] key — Press this key to access analysis features like:
• Trigger level setting.
• Measurement threshold setting.
• Video trigger automatic set up and display.
• Display a bus made up of the analog channel inputs where channel 1 is the least significant bit
and channel 4 is the most significant bit. See also "Analog Bus Display" on page 39.
• Enable serial bus decodes. See also "Serial Bus Decode/Trigger" on page 76.
• Reference waveforms (see "Reference Waveforms" on page 46).
• Mask testing (see "Mask Testing" on page 65).
• Digital voltmeter (see "Digital Voltmeter" on page 72).
• Frequency response analysis on models with a built-in waveform generator (see "Frequency
Response Analysis" on page 73).
•[Meas] key — Press this key to access a set of predefined measurements. See
"Measurements" on page 63.
•[Cursors] key — Press this key to open a menu that lets you select the cursors mode and source.
• Cursors knob — Push this knob select cursors from a popup menu. Then, after the popup menu
closes (either by timeout or by pushing the knob again), rotate the knob to adjust the selected
cursor position.
