82 Keysight InfiniiVision DSOX1204A/G Oscilloscopes User's Guide
2 Quick Reference
Save/Recall (Setups, Screens, Data)
Oscilloscope setups, reference waveforms, and mask files can be saved to internal
oscilloscope memory or to a USB storage device and recalled later. You can also
recall default or factory default setups.
Oscilloscope screen images can be saved to a USB storage device in BMP or PNG
formats.
Acquired waveform data can be saved to a USB storage device in
comma-separated value (CSV), ASCII XY, and binary (BIN) formats.
There is also a command to securely erase all the oscilloscope's non-volatile
internal memory.
Table 30 Save/Recall Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
Save setup files,
screen images,
waveform data, mask
files
[Save/Recall] > Save >
You can also configure the [Quick Action] key to save setups, screen images, or data. See
"Configuring the [Quick Action] Key" on page 92.
Save setup files [Save/Recall] > Save > Format, Setup (*.scp)
Press to Save
Save screen images [Save/Recall] > Save > Format,
• 8-bit Bitmap image (*.bmp)
• 24-bit Bitmap image (*.bmp)
• 24-bit image (*.png)
Settings >
•Setup Info
• Invert Grat
•Palette (Color, Grayscale)
