Analog Bus Display
You can display a bus made up of the analog channel inputs. Any of the input
channels can be assigned to the bus. The bus values display appears at the
bottom of the graticule. Channel 1 is the least significant bit and channel 4 is the
most significant bit.
Table 6 Analog Bus Display Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
Analog bus, display
[Analyze] > Features, Entry knob to select Analog Bus Analysis, push Entry knob to enable or
disable
Analog bus, channel
assignment
[Analyze] > Channel, Entry knob, push Entry knob to make or clear assignment
Analog bus, value
number base
[Analyze] > Base, Entry knob (Hex, Binary)
Analog bus, threshold
source
[Analyze] > Source, Entry knob (1, 2, 3, 4), push Entry knob to toggle between source and
threshold
Analog bus, threshold
level for selected
source
[Analyze] > Threshold, Entry knob, push Entry knob to toggle between source and threshold
