Print (Screens)
You can print the complete display, including the status line and softkey labels, to
a USB printer or a network printer.
To set up a printer:
1 Connect a printer. You can:
• Connect a USB printer to the rectangular USB host port on the front panel.
For the most up-to-date information on printers that are compatible with the
InfiniiVision oscilloscopes, please visit
www.keysight.com/find/InfiniiVision-printers.
• Set up a network printer connection. See "To set up network printer
connections" on page 86.
2 To open the Print Config menu:
• Press [Save/Recall] > Print.
• Select the Quick Print quick action ([Utility] > Quick Action > Action, Quick Print);
then, press Settings.
Some softkeys in the Print Config menu are ghosted (not available) until a
printer is connected.
Table 31 Print Config Menu Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
Printer selection Print to, (printer)
Print options Options,
• Setup Information
• Invert Graticule Colors
• Form Feed
• Landscape
Color or grayscale
printing
Palette, (Color, Grayscale)
Print the current
screen
Press to Print
