Utility Settings
This section explains oscilloscope utility functions.
Table 32 Utility Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
I/O setup [Utility] > I/O >
The oscilloscope can be accessed and/or controlled remotely using these interfaces:
• USB device port on the rear panel (square shaped USB port).
Connect the USB device port to a computer only when the oscilloscope is turned off or when the
oscilloscope is fully booted up and running. If you make this connection while the oscilloscope is
booting up, you will likely get a "USB device not recognized" error.
• LAN interface on the rear panel.
The oscilloscope can be controlled using both I/O interfaces at the same time.
For more information, see the Programmer's Guide.
File explorer [Utility] > File Explorer >
From the internal file system, under "/User Files", you can load oscilloscope setup files (from 10
locations) or mask files (from four locations).
From a connected USB storage device, you can load setup files, mask files, license files, firmware
update (*.ksx) files, label files, etc. Also, you can delete files on a connected USB storage device. See
also "USB Storage Devices" on page 91.
The rectangular USB port on the front panel is a USB Series A receptacle to which you can connect
USB mass storage devices and printers.
NOTE: To properly unmount a USB storage device before removal, press the Eject softkey. If you
remove the device without pressing the Eject softkey first, the device will be marked as needing
repair when connecting to a computer with the Windows operating system (even though there are no
harmful effects to the device).
V/div expansion
options
[Utility] > Options > Preferences > Expand,
• Ground
• Center
Transparent
backgrounds
[Utility] > Options > Preferences > Transparent
Screen saver [Utility] > Options > Preferences > Screen Saver >
Autoscale preferences [Utility] > Options > Preferences > Autoscale >
