62 Keysight InfiniiVision DSOX1204A/G Oscilloscopes User's Guide
2 Quick Reference
Table 18 Cursor Features
Feature Front Panel Key/Softkey Location (see built-in help for more information)
Cursors mode [Cursors] > Mode
Manual cursors mode [Cursors] > Mode, Manual (and use Cursors knob to select and adjust)
Track Waveform
cursors mode
[Cursors] > Mode, Track Waveform
Measure cursors
mode
[Meas] (cursors show locations used for most recently added measurement)
Binary cursors mode [Cursors] > Mode, Binary
Hex cursors mode [Cursors] > Mode, Hex
Cursors X units [Cursors] > Units > X Units (Seconds, Hz, Phase, Ratio)
Cursors Y units [Cursors] > Units > Y Units (Base, Ratio)
