86 Keysight M8194A 120 GSa/s Arbitrary Waveform Generator User Guide
3 M8194A Soft Front Panel
This tab has the following controls and indicators:
Input File Section
• File Format
For details on the available file format, see File Format.
Sample waveform data files are available in different formats as listed in
the Table 7 on page -86. The files can be simply imported using the
Input File section and can be sent to the instrument to view the
waveform preview. The sample waveform data can be found at the
location: Start > All Programs > Keysight M8194 > Keysight M8194
Examples
Steps to view the sample data file waveform preview:
1 Select the Show Next Waveform Preview check box.
2 Select the required File Format from the drop-down list.
3Click File…
4In the Open dialog box, select the sample waveform file (as per
selected file format)
5Click Open.
6Click Send to Instrument.
Table 7 Sample waveform data files
File format Waveform data file
TXT Sin125MHzAt120GHz.txt
BIN Sin125MHzAt120GHz.bin
BIN8 Sin125MHzAt120GHz.bin8
BIN6030 Sin125MHzAt120GHz.bin6030
BIN5110 SinDelta125MHzIQ.bin5110
IQBIN SinDelta125MHzIQ.iqbin
MAT89600 Sin125MHzAt120GHz.mat89600
CSV Sin125MHzAt120GHz.csv
DSA90000 Sin125MHzAt120GHz.dsa90000
