Keysight M8194A 120 GSa/s Arbitrary Waveform Generator User Guide 89
M8194A Soft Front Panel 3
For MAT89600 file and CSV file with data header, the mapping shown
below applies:
Table 10 Modified column-to-channel mapping in four-channel mode
Table 11 Modified column-to-channel mapping in two-channel mode
• I/Q Toggle buttons
I/Q selection toggle buttons for each channel is shown when the file
containing an I/Q waveform is selected for import. In-Phase (I) and
Quadrature (Q) components can be independently assigned to each
channel.
• Segment Number
The segment number is 1. Please note that the segment number
section is only kept for compatibility to M8195A AWG.
Name of column Import and download to M8194A, when corresponding channel
box is selected
Y1 Ch 1
Y2 Ch 2
Y3 Ch 3
Y4 Ch 4
Name of column Import and download to M8194A, when corresponding channel
box is selected
Y1 Ch 1
Y2 Ch 2
Y3 Ignored
Y4 Ch 4, if Y2 is not present; ignored, if Y2 is present
