Trigger the Measurement
The trigger system is waiting for a trigger signal in the initiated state. You can immediately trigger the
measurement as follows:
Front Panel Menu Reference SCPI Command
Not available To generatea measurement trigger:
TRIG:ACQ (@1)
Alternatively, if the trigger source is BUS, you can also
program a *TRG or an IEEE-488 <get> command.
As previously discussed, a trigger can also be generated by another output channel or an input pin on
the digital port connector. If any of these systems are configured as the trigger source, the instrument
will wait indefinitely for the trigger signal. If the trigger does not occur, you must manually return the
trigger system to the idle state.
The following commands return the trigger system to the idle state:
Front Panel Menu Reference SCPI Command
Select Measure\Control.
Then selectthe Abort control.
ABOR:ACQ (@1)
Fetch the Measurement
After a trigger is received and the measurement completes, the trigger system will return to the idle
state. When this occurs, you can use FETCh queries to return the measurement data.
Front Panel Menu Reference SCPI Command
Not available To return average voltage & current:
FETC:VOLT? (@1)
FETC:CURR? (@1)
To return RMS voltage &current:
FETC:VOLT:ACDC? (@1)
FETC:CURR:ACDC? (@1)
To return the high or low level of a pulse:
FETC:VOLT:HIGH? (@1)
FETC:CURR:HIGH? (@1)
FETC:VOLT:LOW? (@1)
FETC:CURR:LOW? (@1)
To return the maximum or minimum value:
FETC:VOLT:MAX? (@1)
FETC:CURR:MAX? (@1)
FETC:VOLT:MIN? (@1)
FETC:CURR:MIN? (@1)
To return power:
FETC:POW? (@1)
