Kia Ceed - Page 648

828
Maintenance
Instrument panel (Driver’s side fuse panel)
Fuse Name Symbol Fuse rating Circuit Protected
MEMORY 1
MEMORY
1
10A
Driver IMS (Integrated memory system) Module, Air Conditioner Control Module, Power Tail
Gate Module
MODULE 1
MODULE
1
10A
Active Air Flap, Data Link Connector, Instrument Cluster, Hazard Switch, ICM (Integrated
Circuit Module) Relay Box (Outside Mirror Folding/Unfolding Relay), Auto Light & Photo
Sensor, Console Switch, Driver/Passenger Smart Key Outside Handle
TAIL GATE 10A Tail Gate Relay
POWER WINDOW
RH
RH
25A
Power Window Right Handle side Relay, Driver/Passenger Safety Power Window Module,
Rear Safety Power Window Module Right Handle side
POWER WINDOW
LH
LH
25A
Power Window Left Handle side Relay, Driver/Passenger Safety Power Window Module,
Rear Safety Power Window Module Left Handle side
POWER SEAT
DRIVER
DRV
25A Driver IMS (Integrated memory system) Module, Driver Seat Manual Switch
MODULE 4
MODULE
4
7.5A
Smart Parking Assist Control Module, Crash Pad Switch, IBU (Integrated Body Control
Unit), Lane Keeping Assist-Line Unit, Blind-Spot Collision Warning Unit Left Handle
side/Right Handle side, Electric Parking Brake Switch, Dosing Control Module, Active Air
Flap, Forward Collision-Avoidance Assist Unit
E-CALL
E-CALL
10A MTS (Mozen Telematics System) E-Call Module
SEAT HEATER
REAR
REAR
20A Rear Seat Warmer Control Module
HEATED MIRROR 10A
Driver/Passenger Power Outside Mirror, Air Conditioner Control Module, ECM (Engine
Control Module)/PCM (Power train Control Module)
SEAT HEATER
FRONT
FRT
20A Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module
