883
Maintenance
Fuse Name Symbol Fuse rating Circuit Protected
AMP
AMP
25A Low DC (Direct Current)-DC (Direct Current) Converter (AMP (Amplifier)), AMP (Amplifier)
MULTI MEDIA
MULTI
MEDIA
15A
Low DC (Direct Current)-DC (Direct Current) Converter (Audio/AMP (Amplifier)), Audio,
Audio/Video & Navigation Head Unit
MODULE 5
MODULE
5
10A
Electric Parking Brake Switch, Rear Seat Warmer Control Module, MTS (Mozen Telematics
System) E-Call Module, Electro Chromic Mirror, Audio, Audio/Video & Navigation Head
Unit, Auto Transmission Shift Lever Illumination, Air Conditioner Control Module, Low DC
(Direct Current)-DC (Direct Current) Converter (Audio/AMP (Amplifier)), Front Seat Warmer
Control Module, Front Air Ventilation Seat Control Module, Driver IMS (Integrated memory
system) Module, Head Lamp Left Handle side/Right Handle side
REAR WIPER 15A Rear Wiper Motor, ICM (Integrated Circuit Module) Relay Box (Rear Wiper Relay)
DOOR LOCK 20A Door Lock/Unlock Relay
IBU 1
IBU
1
15A IBU (Integrated Body Control Unit)
BRAKE SWITCH
BRAKE
SWITCH
10A IBU (Integrated Body Control Unit), Stop Lamp Switch
POWER SEAT
PASSENGER
PASS
10A Front Seat Warmer Control Module, Front Air Ventilation Seat Control Module
IG 1
IG1
25A Engine Room Junction Block (Fuse - ECU5, SENSOR4, ABS3, TCU2)
WIPER
LO/HI
10A
Engine Room Junction Block (Front Wiper (Low) Relay), Front Wiper Motor, IBU (Integrated
Body Control Unit), ECM (Engine Control Module)/PCM (Power train Control Module)
AIR
CONDITIONER 1
A/C
1
7.5A
Engine Room Junction Block (COOLING FAN 3 Relay, PTC HEATER 2 Relay, BLOWER
Relay, PTC HEATER 1 Relay, PTC HEATER 3 Relay), Air Conditioner Control Module
