Kia Ceed - Page 650

848
Maintenance
Fuse Name Symbol Fuse rating Circuit Protected
AIR BAG 2
2
10A SRS (Supplemental Restraint System) Control Module
WASHER 15A Multifunction Switch
MDPS
1
7.5A MDPS (Motor Driven Power Steering) Unit
MODULE 7
MODULE
7
7.5A
Rear Seat Warmer Control Module, Front Seat Warmer Control Module, Front Air Ventilation
Seat Control Module, Nozzle Heater, Engine Room Junction Block (HEAD LAMP HIGH
Relay, DCU (Dosing Control Unit) Relay), Cooling Fan Motor
SUNROOF 2
2
20A Panorama Sunroof Motor
SUNROOF 1
1
20A Panorama Sunroof Motor
CLUSTER CLUSTER 7.5A Instrument Cluster
MODULE 3
MODULE
3
7.5A Sport Mode Switch, Stop Lamp Switch
START 7.5A
ICM (Integrated Circuit Module) Relay Box (Burglar Alarm Relay), Transaxle Range Switch,
Engine Room Junction Block (PDM 3 (IG1) Relay), IBU (Integrated Body Control Unit),
ECM (Engine Control Module), PCM (Power train Control Module)
IBU 2
IBU
2
7.5A IBU (Integrated Body Control Unit)
AIR BAG
INDICATOR
IND
7.5A Instrument Cluster, Hazard Switch
