Fuse Name Symbol Fuse rating Circuit Protected
MODULE 6
MODULE
6
7.5A IBU (Integrated Body Control Unit)
MODULE 2
MODULE
2
10A
Audio, Audio/Video & Navigation Head Unit, Low DC (Direct Current)-DC (Direct Current)
Converter (Audio/AMP (Amplifier)), IBU (Integrated Body Control Unit), MTS (Mozen
Telematics System) E-Call Module, Wireless Charger, Engine Room Junction Block
(POWER OUTLET Relay), AMP (Amplifier), Power Outside Mirror Switch
AIR BAG 1
1
15A SRS (Supplemental Restraint System) Control Module
AIR
CONDITIONER 2
A/C
2
10A
Engine Room Junction Block (BLOWER Relay), Air Conditioner Control Module, Blower
Resistor, Blower Motor, ECM (Engine Control Module)/PCM (Power train Control Module)
LDC (B+)
LDC
(B+)
15A
Audio, Audio/Video & Navigation Head Unit, Instrument Cluster, Air Conditioner Control
Module, Low DC (Direct Current)-DC (Direct Current) Converter (Audio/AMP (Amplifier))
POWER OUTLET
POWER
OUTLET
20A Front Power Outlet, Power Outlet Left Handle side
