889
Maintenance
Fuse Name Symbol Fuse rating Circuit Protected
PTC HEATER 1
PTC
HEATER
1
50A PTC HEATER 1 Relay
PTC HEATER 2
PTC
HEATER
2
50A PTC HEATER 2 Relay
PTC HEATER 3
PTC
HEATER
3
50A PTC HEATER 3 Relay
FUEL HEATER 30A FUEL HEATER Relay
POWER
OUTLET 3
POWER
OUTLET
3
20A Rear Power Outlet
POWER
OUTLET 2
POWER
OUTLET
2
20A Front Power Outlet, Power Outlet Right Handle side
DCU 2
DCU
2
20A Dosing Control Module
TCU 1
T1
15A TCM (Transmission Control Module)
VACUUM PUMP
VACUUM
PUMP
20A Vacuum Pump
FUEL PUMP
FUEL
PUMP
20A FUEL PUMP Relay
COOLING FAN 2
2
40A COOLING FAN 3 Relay, COOLING FAN 2 Relay
BATTERY 1
1
40A
Instrument Panel Junction Block (LONG TERM LOAD LATCH RELAY, Fuse : MODULE1,
SEAT HEATER REAR, DOOR LOCK, IBU1, BRAKE SWITCH, AIR BAG2)
DCT 1
DCT
1
40A TCM (Transmission Control Module)
