Kia Ceed - Page 656

908
Maintenance
Fuse Name Symbol Fuse rating Circuit Protected
DCT 2
DCT
2
40A TCM (Transmission Control Module)
BURGLAR ALARM
1
10A Burglar Alarm Relay
HEAD LAMP HIGH 10A HEAD LAMP HIGH Relay
ABS 1
1
40A ESC (Electronic Stability Control) Control Module
ABS 2
2
30A ESC (Electronic Stability Control) Control Module
DCU 1
DCU
1
40A DCU (Dosing Control Unit) Relay
POWER TAIL GATE
MODULE
30A Power Tail Gate Module
POWER OUTLET 1
POWER
OUTLET
1
40A POWER OUTLET Relay
DCU 4
DCU
4
20A Dosing Control Module
DCU 3
DCU
3
15A Dosing Control Module
SENSOR 2
S2
10A
[Kappa 1.4L MPI] Purge Control Solenoid Valve, Variable Intake Solenoid Valve, COOLING
FAN 3 Relay, COOLING FAN 2 Relay, Oil Control Valve (Intake/Exhaust)
[Kappa 1.0L T-GDI] Air Conditioner Compressor Relay, Purge Control Solenoid Valve, RCV
Control Solenoid Valve, COOLING FAN 1 Relay, Oil Control Valve (Intake/Exhaust)
[Kappa 1.4L T-GDI] Air Conditioner Compressor Relay, Purge Control Solenoid Valve, RCV
Control Solenoid Valve, COOLING FAN 1 Relay, Oil Control Valve (Intake/Exhaust)
[Gamma 1.6L MPI] Purge Control Solenoid Valve, Variable Intake Solenoid Valve, COOL-
ING FAN 3 Relay, COOLING FAN 2 Relay, Oil Control Valve (Intake/Exhaust)
[SmartStream D 1.6] Air Conditioner Compressor Relay, PTC HEATER 1 Relay, PM
Sensor, Electronic VGT Actuator, Oil Level Switch
