8-10 Specifications PAS SERIES
*1 The maximum preset voltage and maximum preset current are provided for establishing
a constant current operation when the operation point is at [rated output voltage and
rated output current]. It does not guarantee power supply to the load exceeding the rated
output current.
To establish a constant voltage operation at the operation point [rated output voltage and
rated output current], set the output current (I Set) so that rated output current < I Set ≤
maximum preset current.
Likewise, to establish constant current operation, set the output voltage (V Set) so that
rate output voltage < V Set ≤ maximum preset voltage.
*2 The difference between the actual output current and the preset value under constant cur-
rent operation.
*3 ** % of rating denotes ** % of the rated output current.
*4 Output current fluctuation with respect to ± 10 % fluctuation of the nominal input volt-
age (ex. 100 VAC) under constant current operation.
*5 Output current fluctuation when the output current is set to the rated output current and
the load is changed from rated load to no load under constant current operation.
350W Type
PA S
10-35
PA S
20-18
PA S
40-9
PA S
60-6
PA S
80-4.5
Output Specifications (cont.)
Current Rated output current 35.00 A 18.00 A 9.000 A 6.000 A 4.500 A
Maximum preset current
(typ)
*1
105 % of rating
Accuracy of setting
*2
0.5 % of rating + 20 mA
*3
Source effect
*4
0.1 % of rating + 10 mA
*3
Load effect
*5
0.1 % of rating + 10 mA
*3
Ripple noise (RMS)
*6
77 mA 40 mA 20 mA 13 mA 10 mA
Temperature coefficient
(max)
*7
200 ppm/ °C (during analog remote control)
Series/Parallel operation
Master-slave parallel operation
*8
Up to 5 units including the master unit (same models only)
Master-slave series operation
*9
Up to 2 units including the master unit (same models only)
Input Specifications
Current (max)
*10
5.0 A (100 VAC)/ 2.5 A (200 VAC)
Inrush current (max)
*11
35 Apeak
Power (max)
*10
500 VA
Power factor (typ)
*12
0.980
Efficiency (min)
*13
70%
