50 TOS5200
Starting a Test
● “PASS” or “FAIL” is lit.
You cannot start testing while a judgment result is displayed. Press STOP to switch the
TOS5200 to the READY state.
● “PROTECTION” is lit.
p. 74
If PROTECTION is lit, the TOS5200 has switched to protection mode and will not allow
you to start testing. Resolve the issues causing the PROTECTION mode to be on.
● The double action feature has been turned on.
p. 45
When the double action feature is turned on, you cannot start tests just by pressing
START. Press STOP, and then press START within 0.5 seconds.
A
kV
Mȍ
mA
CONFIG
RISE TEST
RMS AV E MO RE CA L R M T
MT
LIMIT
50Hz 60Hz
UPPER
LOWER W COMP
s
1
2
3
READY
TEST
PAS S
FAIL
PROTECTION
To Next Page
