TOS93 Series User’s Manual 249
Specifications | Insulation resistance test section
Insulation resistance test section
Applicable models: , , ,
Output function
9300
9301
9303
9303LC
Item Specifications
Negative
polarity
Output voltage range -25 V to -1000 V
Resolution 1 V
Setting accuracy ±(1.2 % of setting + 2 V)
Max. rated load 1 W (-1000 V/1 mA)
Ripple 1 kV no load 2 Vp-p or less
Max. rated load 10 Vp-p or less
Short-circuit current 12 mA or less
Positive
polarity
1
Output voltage range +50 V to +7200 V
Resolution 1 V
Setting accuracy ±(1.2 % of setting + 20 V)
Max. rated load 7.2 W(7200 V/1 mA)
Ripple 1 kV no load 20 Vp-p or less
Max. rated load 50 Vp-p or less
Short-circuit current 100 mA (TYP) (200 mA peak)
Max. rated current 1 mA
Voltage regulation 1 % or less (when changing from maximum rated load to no load)
Discharge function Forced discharge after test completion (discharge resistance: 20 kΩ)
Output voltage monitor function If the output voltage exceeds ±(10 % of setting + 50 V), the output is
turned off, and the protection function is activated.
1 TOS9300 are not supported.
