Specifications | Interface
Interface
Measurement
terminal
Rated voltage Between the A
and B terminals
250 V
Between the
terminals and
chassis
250 V
Rated current: 100 mA
Measurement category CAT-II
Valid terminal display Terminals valid for measurement are indicated on the display.
110% terminal Terminal for supplying 110% voltage of the AC line.
Power supply
for the EUT
Nominal voltage range 100 V to 240 V, 50 Hz/60 Hz
Input voltage range (allowable
voltage range)
85 Vac to 250 Vac
Rated output capacity 1500 VA
Maximum operating current 15 A (Overcurrent protection is activated at approximately 15.75 A.)
Inrush current 70 Apeak max. (within 20 ms)
1 If voltage is measured with the A and B terminals open, measurements will be easily affected by induced voltage.
Item Specifications
Item Specifications
REMOTE 5-pin DIN connector. Connect the following option to remotely con-
trol the starting and stopping of tests.
• Remote control box RC01-TOS, RC02-TOS
• High voltage test probe HP01A-TOS, HP02A-TOS
(when the test voltage is 4 kVac 5 kVdc or less)
SIGNAL I/O D-sub 37-pin connector. For the pin arrangement, see p.200 .
Function Enable/disable interlock, recall setup memories, recall auto test
programs, start/stop testing, monitor the test and voltage genera-
tion status, monitor the test status, monitor judgment results, moni-
tor the step execution status of auto tests, monitor the activation
status of protection functions
Input specifications The input signals are all low-active control. The input terminal is
pulled up to +12 V by a resistor. Leaving the input terminal open is
equivalent to applying a high level signal.
High-level input voltage 11 V to 15 V
Low-level input voltage 0 V to 4 V
Low-level input current -5 mA max.
Input time width 5 ms min.
Output
specifications
Output method Open collector output (4.5 Vdc to 30 Vdc)
Output withstanding voltage 30 Vdc
Output saturation voltage Approx. 1.1 V (25 °C)
Maximum output current 400 mA(TOTAL)
STATUS OUT Output terminal of an option product.
Positive terminal (red) Outputs +24 V. Use Status Out of CONFIG settings to set the output
conditions.
Negative terminal (black) +24 V circuit common.
