TOS93 Series User’s Manual 87
Earth Continuity Test | Setting Test Conditions
Limit current
Set the upper limit of current to run through the EUT. This prevents unnecessarily high current from being
run through the EUT by mistake.
1
On the Home menu screen, press Current > Limit Current.
2
Use the numeric keypad or the rotary knob to enter the current.
Setting range: 3.0 A to 42.0 A
This completes the setting.
Frequency
This can be set only for AC tests.
Set the test current frequency to 50 Hz or 60 Hz. / appears during testing according to the set-
ting.
1
On the Home menu screen, press Current > Frequency.
2
Turn the rotary knob to change the value.
This completes the setting.
