TOS93 Series User’s Manual 263
Specifications | Other functions
Other functions
SCANNER MINI DIN 8-pin connector. Terminal for the optional TOS9320 high
voltage scanner. The maximum number of connections is 4 devices
(16 channels).
USB (host) Standard type A socket, FAT32, 32 GB or less
Complies with the USB 2.0 specifications; data rate: 12 Mbps (full
speed)
Remote control All functions except turning on and off the power, key lock, and auto
test can be remotely controlled.
RS232C Hardware D-sub 9-pin connector (EIA-232D compliant)
Baudrate: 9600, 19200, 38400, 57600, 115200 bps
Data length: 8 bits; stop bits: 1 bit; parity bit: none, flow control:
none/CTS-RTS
Message terminator LF during reception, LF during transmission.
USB (device) Hardware Standard Type B connector
Complies with the USB 2.0 specifications; data rate: 480 Mbps
(high speed)
Message terminator LF or EOM during reception, LF + EOM during transmission.
Device class Complies with the USBTMC-USB488 device class specifications.
LAN Hardware IEEE 802,3 100Base-TX/10Base-T Ethernet
Auto-MDIX compliant.
IPv4, RJ-45 connector.
Compliant standards LXI 1.4 Core Specification 2011
Communication protocol VXI-11, HiSLIP, SCPI-RAW, SCPI-Telnet
Message terminator VXI-11, HiSLIP: LF or END during reception, LF + END during
transmission.
SCPI-RAW: LF during reception, LF during transmission.
Display 7-inch LCD
Item Specifications
Item Specifications
Auto test Auto execution by combining ACW, DCW, IR, and EC. For LC, a combination is
possible only using TC, PCC, and Patient. Up to 20 programs containing up to 100
steps can be created.
Test condition
memory
Setup memory Up to 50 test conditions (ACW, DCW, IR, EC) can be saved.
Program memory Up to 25 program (ACW, DCW, IR, EC) combinations, each containing 100 steps,
can be saved.
Program memory
(LC)
Up to 25 program (TC, PCC, Patient) combinations, each containing 100 steps,
can be saved.
Test result memory Records up to 1000 latest test result of independent tests and auto tests. These
are cleared when the power is turned off. Test results can be saved in CSV format
to a USB memory device.
System clock For recording the calibration time and test times
Recordable time Up to year 2038
Calibration period
setting
Displays a warning at power-on when the specified period passes. Select whether
to activate a protection function or only display a warning in the display area when
a warning occurs.
