282 User’s Manual TOS93 Series
Appendix | Options
High voltage test probe
The HP01A-TOS/HP02A-TOS high voltage test probe is for outputting test voltages in ACW and DCW
tests. The probe has to be operated with both hands to output the test voltage. This prevents the test volt-
age from being output inadvertently. A DIN adapter cable (p.281) is required to connect to the TOS93.
Warning light unit
The PL02-TOS warning light unit indicates that a test is in progress or other statuses. You can view the
status from a distance.
The maximum rated voltages of the HP01A-TOS/HP02A-TOS are 4 kVac and 5 kVdc.
For safety reasons, set the product’s limit voltage (p.52) to limit the applied voltage.
