E3 4K HDMI/3G-SDI Encoder User Manual
14
Copyright@2023 KILOVIEW Electronics Co., LTD
7 Parameter Configuration
7.1 Encoding Mode Selection
E3 supports 3G-SDI, HDMI dual interface input/loop out. Users can choose the HDMI or/and SDI
interfaces as the video input source, and can dynamically switch the input source. Users can also
choose to synthesize the video input of HDMI and SDI and then encode the output. Modify the
encoding parameters of the device by clicking the HDMI, SDI, and Mix switches on the page.
Mix (mix coding) settings
Click the Mix encoding mode on the left side of the home page, and then click the
encoding switch button on the right, a dialog box will pop up to prompt that this
operation will exit the HDMI/SDI encoding mode and switch to the mixed encoding
mode that supports picture-in-picture, click OK.
