Kinco SV100 Series User Manual

59
frequency
【0.00】
This parameters is used to monitor the estimated motor
rotor frequency under the condition of open-loop vector
control.
d0.11 Motor actual
frequency
－ 300.00 ～ 300.00Hz
【0.00】
This parameter is used to monitor the actual motor rotor
frequency measured by encoder under the condition of
close-loop vector control.
d0.12 Bus voltage
0
～
800V
【
0
】
This parameter is used to monitor the drive’s bus
voltage.
d0.13 Drive operation
status
0000
～
FFFFH
【
0000
】
Fig.6-46 The drive’s operation status
d0.14 Input terminals status
00～FFH【00】
Fig.6-47 Input terminals status
This parameter is used to display the status of X1～X7.
0 indicates OFF status,1 indicates ON status.
d0.15 Output terminals status
0～1FH【0】
Fig.6-48 Output terminal status
This parameter is used to display the status of output
terminals.When there is signal output,the corresponding
bit will be set as 1.
d0.16 AI1 input
－10.00～10.00V【0.00】
d0.17 AI2 input
－10.00～10.00V【0.00】
d0.18 AI3 input
－10.00～10.00V【0.00】
d0.16～d0.18 are used to display the analog input value
before regulation.
d0.19 Percentage of AI1 after
regulation
-100.0%～100.0%【0.0】
d0.20 Percentage of AI2 after
regulation
-100.0%～100.0%【0.0】
d0.21 Percentage of AI3 after
regulation
-100.0%～100.0%【0.0】
d0.19～d0.21 are used to display the percentage of
analog input after regulation.
D
BIT0
：
Y1
terminal status
BIT1
：Reserved
BIT2
：
R01
relay status
BIT
3
：
Reserved
BIT4：Y2 terminal status
C
D
BIT0
：
X1
terminal status
BIT1
：
X2
terminal status
BIT2
：
X3
terminal status
BIT
3
：
X4
terminal status
BIT0
：
X5
terminal status
BIT1
BIT2
：
BIT
3
：
Reserved
A
B
C
D
BIT0
：
0:Stop. 1:Run
BIT1
：
0:Forward. 1:Reverse
BIT2
：Operating at zero frequecy
BIT
3
：Accelerating
BIT0
：Decelerating
BIT1
：Operating at constant speed
BIT2
：Pre-commutation
BIT
3
：Tuning
BIT0
：Over-current limiting
BIT1
：DC over-voltage limiting
BIT2
：Torque limiting
BIT
3
Reversed
BIT0
：Drive fault
BIT1
：Speed control
BIT2
：Reserved
BIT
3
：Reserved
