Kinco SV100 Series User Manual

60
d0.22 AO1 output
0.0%～100.0%【0.0】
d0.23 AO2 output
0.0%～100.0%【0.0】
d0.22、d0.23 are used to diplay the percentage of analog
output that corresponding to the full range.
d0.24 Process close-loop
reference
-100.0%～100.0%【0.0】
d0.25 Process close-loop
feedback
-100.0%～100.0%【0.0】
d0.26 Process close-loop
error
-100.0%～100.0%【0.0】
d0.27 Process close-loop
output
-100.0%～100.0%【0.0】
d0.28 Temperature of heatsink 1
0.0～150.0℃【0.0】
d0.29 Temperature of heatsink 2
0.0～150.0℃【0.0】
Temperature of heatsink 1 is the temperature of IGBT
modules. Different IGBT modules have different
over-temperature threshold.
Temperature of heatsink 2 is the temperature of rectifier.
The drive of 30kW or below does not detect this
temperature.
Temperature display range:0～100℃.Accuracy：5％
d0.30 Total conduction time
0～65535 hours【0】
d0.31 Total operating time
0～65535 hours【0】
d0.32 Total fan’s operating time
0～65535 hours【0】
d0.30 ～ d0.32 define the drive’s total conduction
time,operating time and fan’s operating time after
production.
d0.33 ASR controller output
-300.0~300.0%
(Corresponding to
rated torque of motor
d0.34 Reference torque
-300.0~300.0%
(Corresponding to
rated torque of motor
6.19 Group d1
d1.00 Fault record 1
0～50【0】
d1.01 Bus voltage of the latest
failure
0～999V【0】
d1.02 Actual current of the latest
failure
0.0～999.9A【0】
d1.03 Operation frequency of the
latest failure
0.00~300.0Hz【0.00】
d1.04 Operation status of the
latest failure
0～FFFFH【0000】
d1.05 Fault record 2
0～50【0】
d1.06 Fault record 3
0～50【0】
SV100 support 50 kinds of protection alarm and can
record the latest three fault code (d1.00,d1.05,d1.06) and
bus voltage, current,operation frequency and operation
status of the latest fault.
Fault record 1 is the latest fault record.
See Chapter 7 of failure and alarm information during
failures recently occurred for the ease of Trouble
Shooting and repair.
6.20 Group d2
d2.00 Serial number
0~FFFF【100】
d2.01 Software version
number
0.00~99.99【1.00】
d2.02 Custom-made version
number
0~9999【0】
d2.03 Rated capacity
0~999.9KVA【Factory】
d2.04 Rated voltage
0~999V【Factory】
d2.05 Rated current
0~999.9A【Factory 】
This group of parameters can be changed by user.
