5.1.2 Function Descriptions of LED and Indicators
The operation panel consists of a 5-digits eight segments lED display, 3 LED indicators that indicate unit and 3 status
indicators as shown in Fig.5-1. The LED display can display the status parameters, function codes and error codes of
the drive. The 3 unit indicators are corresponding to three units, the descriptions of three status indicator are shown in
table 5-2
Table 5-2
Indicator
Status
Current status of drive
Operating status
indicator(RUN)
Off
Stop
On
Operating
Operating
direction
indicator(FWD)
Off
Forwards
On
Reverse
Operating mode
indicator(MON)
On
Operation panel control
Off
Terminal control
Flashing
Communication control
5.1.3 Display status of operation panel
SV100 operation panel can display the parameters in stopping, operating, editing and function code..
1. Parameters displayed in stopping status
When the drive is in stop status, the operation panel displays the stop staus parameter. Pressing the SHIFT key can
display different stop status parameters in cycle (Defined by function code b4.05)
2. Parameters displayed in operation status
When the drive receives operating command, it starts running and its panel will display the operation status parameters,
the RUN indicator turns on. The status of FWD indicator depends on the operation direction. The unit indicator display
the unit of the parameter, by pressing the SHIFT key can display different operation parameters in cycle (Defined by
function code b4.05)
3. Parameters displayed in error status
When the drive detects a fault signal, the panel will display the flashing fault code..
Press the SHIFT key to display the stop staus parametere and error code in cycle. By pressing the STOP/RST, control
terminal or communication command to reset the error. If the error exists still, then the panel keeps displaying the error
code.
4. Parameter edit status
When the drive is in stop, operation or error state, press MENU can enter edit status(If password needed, please refer
to description of A0.00),. Edit state displays in 2-level menu, they are: function codegroup or function code
number→function code parameter value. You can press ENTER to enter parameter displayed status. In function
parameter displayed sttatus, press ENTER to save the settings, and press MENU to exit the menu.
