Press the ENTER and hold , then press the ∨ three times
Note:
Whatever setting is in b4.00, after the VFD power on, the operation board is in unlock status.
5.2 Operation mode of VFD
In the follow-up sections, you may encounter the terms describing the control, running and status of drive many times.
Please read this section carefully. It will help you to understand and use the functions discussed in the follow chapters
correctly.
5.2.1 Control mode of VFD
It defines the physical channels by which drive receives operating commands like START, STOP, JOG and others,
there are two channels:
1 Operation panel control: The drive is controlled by RUN, STOP and M keys on the operation panel;
2 Terminal control: The drive is controlled by terminals Xi、Xj and COM (2-wire mode), or by terminal Xki (3-wire
mode);
The control modes can be selected by function code A0.04, multi-function input terminal (Function No. 15~17 are
selected by A6.00~A6.06 )
Note:
Before you change the control mode, make sure that the mode suitable for the application. Wrong selection of control
mode may cause damage to equipment or human injury!
5.2.2 Operating Status
There are 3 operating status: stop, motor parameters auto-tuning, and operating.
1.Stop status: After the drive is switched on and initialized, if no operating command is accepted or the stop command
is executed, then the drive in stop status.
2.Operating status: The drive enters operating status after it receives the operating command.
3.Motor parameters auto-tuning status: If there is an operating command after b0.11 is set to 1 or 2, the drive
then enters motor parameters auto-tuning status, and then enters stopping status after auto-tuning process finishes.
5.2.3 Control mode and operation mode of Kinco VFD
Control mode
SV100 VFD has three control methods, it is set by A0.01:
0. Vector control without PG: it is vector control without speed sensor, need not to install the PG, at the same time it
has very high control performance, it can control the speed and torque of motor accurately. It has the characteristics
like low frequency with high torque and steady speed with high accuracy. It is often used in the applications that the
V/F control mode can not stisfy, but requires high robustness.
1. Reserved
2. V/F control: It is used in the applications that do not require very high performance, such as one VFD controls
multiple motors.
