Kinco SV100 Series User Manual

6
Auxiliary
frequency setting
Implement flexible auxiliary frequency trim and frequency synthesis.
Pulse output
0~100KHz pulse output.
Analog output
2 channels analog output(0/4~20mA or 0/2~10V).
Operatio
n panel
LED Display
Display setting frequency, output frequency , output voltage, output current and so on,
about 20 parameters.
Parameters copy
Copy parameters by operation panel.
Keys lock and
function selection
Lock part of keys or all the keys. Define the function of part of keys
Protection function
Open phase protection (optional), overcurrent protection, overvoltage protection,
undervoltage protection, overheat protection, overload protection and so on.
Envi
ron
ment
Operating site
Indoor , installed in the environment free from direct sunlight, dust, corrosive gas,
combustible gas, oil mist, steam and drip.
Altitude
Derated above 1000m, the rated output current shall be decreased by 10% for every
rise of 1000m
Ambient temperature
-10℃~40℃, derated at 40℃~ 50℃
Humidity
5%~95%RH, non-condensing
Vibration
Less than 5.9m/s2 (0.6g)
Storage temperature
－40℃～＋70℃
Stru
cture
Protection class
IP20
Cooling method
Air cooling, with fan control.
Installation method
Wall-mounted
Effeciency
Power under 45kW≥93%；Power above 55kW≥95%
2.2 Introduction of product series
Table 2-1 Series of Kinco VFD
Model of VFD
Rated capacity
（kVA）
Rated input current
（A）
Rated output current
（A）
Motor power
（kW）
SV100-2S-0004G
1.0
5.3
2.5
0.4
SV100-2S-0007G
1.5
8.2
4.0
0.75
SV100-2S-0015G
3.0
14.0
7.5
1.5
SV100-2S-0022G
4.0
23.0
10.0
2.2
SV100-4T-0007G
1.5
3.4
2.3
0.75
SV100-4T-0015G
3.0
5.0
3.7
1.5
SV100-4T-0022G
4.0
5.8
5.5
2.2
SV100-4T-0037G
5.9
10.5
8.8
3.7
