Kinco SV100 Series User Manual

103
6.Control parameters and status parameters of VFD
The control parameters of VFD can achieve the function such as startup, stop,setting operating frequency and so
on.Retrieving the status parameters of VFD can obtain the parameters such as operating frequency,output
current,output torque and so on.
1．Control parameter
The control parameters of VFD are shown in following table.
Register
Parameter Name
Saved after powered off
Note
0X3200
Control word 1
No
0x3201
Main setting
No
The main setting
frequency: In the common
operation mode, the
channel of main setting is
serial communication, it
tack effects if the bit8 of
control word 1 is set on.
Wether it saves or not
depends on the setting in
A2.03
0x3202
Operation frequency setting
No
Same as above
0x3203
Digital closed loop setting
yes
Takes effects after the
closed loop is enabled
0x3204
Pulse closed loop setting
/
Do not support
0x3205
Analog outprut AO1 setting
No
Enable when A6.28=15
0x3206
Analog outprut AO2 setting
No
Enable when A6.29=15
0x3207
Digital output DO setting
No
Enable when A6.25=65
0x3208
Frequency Proportion
setting
Do not support
0x3209
Virtual terminal control
setting
No
Bit~bit6: X1~X7.
Corresponding to on state
of the bits in A6.24
Bit10~bit13:
Y1/Y2/RO1/RO2, They are
enabled when
A6.14~A6.17=17
0x320A
Set the acceleration time
Yes
0x320B
Set the deceleration time
Yes
Ox3212
Control command word 2
No
Note:
（1）When read control parameters,it will return the value which is rewrote in the previous communication.
（2）In control parameters,the preset value,range of input/output setting value and decimal point scaling should
refer to the corresponding function code.
