Kinco SV100 Series User Manual

62
Fault code
Fault categories
Possible reasons for fault
Actions
E007
Drive’s control
power supply
over voltage
Abnormal AC supply voltage
Check the AC supply voltage
or seek service
E008
Input phase
loss
Any of phase R, S and T cannot be detected
Check the wiring and
installation
Check the AC supply voltage
E009
Output phase
loss
Any of Phase U, V and W cannot be detected
Check the drive’s output
wiring
Check the cable and the
motor
E010
Protections of
IGBT act
Short-circuit among 3-phase output or
line-to-ground short circuit
Rewiring, please make sure
the insulation of motor is
good
Instantaneous over-current
Refer to E001~E003
Vent is obstructed or fan does not work
Clean the vent or replace the
fan
Over-temperature
Lower the ambient
temperature
Wires or connectors of control board are loose
Check and rewiring
Current waveform distorted due to output
phase loss
Check the wiring
Auxiliary power supply is damaged or IGBT
driving voltage is too low
Seek service
Short-circuit of IGBT bridge
Seek service
Control board is abnormal
Seek service
E011
IGBT module’s
heatsink
overheat
Ambient over-temperature
Lower the ambient
temperature
Vent is obstructed
Clean the vent
Fan does not work
Replace the fan
IGBT module is abnormal
Seek service
E012
Rectifier’s
heatsink
overheat
Ambient over-temperature
Lower the ambient
temperature
Vent is obstructed
Clean the vent
Fan does not work
Replace the fan
E013
Drive overload
Parameters of motor are wrong
Atuo-tune the parameters of
motor
Too heavy load
Select the drive with bigger
power
DC injection braking current is too big
Reduce the DC injection
braking current and prolong
