Kinco SV100 Series User Manual

76
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
1：Reserved
A4.01
Acc time 2
0.0~6000.0
0.1S
20.0S
○
0~60000
A4.02
Dec time 2
0.0~6000.0
0.1S
20.0S
○
0~60000
A4.03
Acc time 3
0.0~6000.0
0.1S
20.0S
○
0~60000
A4.04
Dec time 3
0.0~6000.0
0.1S
20.0S
○
0~60000
A4.05
Acc time 4
0.0~6000.0
0.1S
20.0S
○
0~60000
A4.06
Dec time 4
0.0~6000.0
0.1S
20.0S
○
0~60000
A4.07~A
4.10
Reserved
Group A5：Control parameters
A5.00
Speed/torque
control mode
0：Speed control mode
1：Torque control mode
1
0
×
0~1
A5.01
ASR1-P
0.1~200.0
0.1
20.0
○
1~2000
A5.02
ASR1-I
0.000~10.000S
0.001S
0.200s
○
0~10000
A5.03
ASR1 output filter
0~8(Corresponding to
0~2^8/10ms）
1
0
○
0~8
A5.04
ASR2-P
0.1~200.0
0.1
20.0
○
1~2000
A5.05
ASR2-I
0.000~10.000S
0.001S
0.200s
○
0~10000
A5.06
ASR2 output filter
0~8（Corresponding to
0~2^8/12.5ms）
1
0
○
0~8
A5.07
ASR1/2 switching
frequency
0.0%~100.0%
0.1
10.0％
○
0~1000
A5.08
Maximum speed
limit for forward
running when
torque control
0.0%~+100.0%
0.1％
100.0％
○
0~1000
A5.09
Maximum speed
limit for reverse
running when
torque control
0.0%~+100.0%
0.1％
100.0％
○
0~1000
A5.10
Driving torque
limit
0.0%~+300.0%
0.1%
180.0%
○
0~3000
A5.11
Braking torque
limit
0.0%~+300.0%
0.1%
180.0%
○
0~3000
A5.12
Reserved
A5.13
Reserved
