Kinco SV100 Series User Manual

96
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
d0.15
Output terminals
status
0~1FH，0：OFF；1：ON
1
0
*
0~1FH
d0.16
AI1 input
-10.00~10.00V
0.01V
0.00
*
0~2000
d0.17
AI2 input
-10.00~10.00V
0.01V
0.00
*
0~2000
d0.18
Reserved
d0.19
Percentage of AI1
after regulation
-100.00%~110.00%
0.01%
0.00
*
0~20000
d0.20
Percentage of AI2
after regulation
-100.00%~110.00%
0.01%
0.00
*
0~20000
d0.21
Reserved
-100.00%~110.00%
0.01%
0.00
*
0~20000
d0.22
AO1 output
0.0~100.0% (Ratio of the full
range)
0.1%
0.0%
*
0~1000
d0.23
AO2 output
0.0~100.0% (Ratio of the full
range)
0.1%
0.0％
*
0~1000
d0.24
Process close-loop
reference
-100.0~100.0% (Ratio of the full
range)
0.1%
0.0%
*
0~2000
d0.25
Process close-loop
feedback
-100.0~100.0% (Ratio of the full
range)
0.1%
0.05%
*
0~2000
d0.26
Process close-loop
error
-100.0~100.0% (Ratio of the full
range)
0.1%
0.0%
*
0~2000
d0.27
Process close-loop
-100.0~100.0% (Ratio of the full
range)
0.1%
0.0%
*
0~2000
d0.28
Temperature of
heatsink 1
0.0~150.0℃
0.1℃
0.0
*
0~1500
d0.29
Temperature of
heatsink 2
0.0~150.0℃
0.1℃
0.0
*
0~1500
d0.30
Total conduction
time
0~65535 hours
1 hours
0
*
0~65535
d0.31
Total operating
time
0~65535 hours
1 hours
0
*
0~65535
d0.32
Total fan’s
operating time
0~ 65535 hours
1 hours
0
*
0~65535
d0.33
ASR controller
output
-300.0~300.0% (Corresponding to
drive’s rated torque）
0.1%
0.0%
*
0~6000
d0.34
Reference torque
-300.0~300.0%（Corresponding to
drive’s rated torque）
0.1％
0.0％
*
0~6000
