OPERATION TIP FOR 3-POINT HITCH ELEMENTS
(3) Lift Rod (R)
(4) Check Chain
(1) Lift Rod (2) Lift Rod Turn Buckle
(3) Lock Nut
1. Adjust the implement balance by
turning the lift rod turn buckle.
2. After adjustment, secure it with the
lock nut.
(1) Top Link
(2) Lift Rod (L)
ADJUSTMENT OF LIFT ROD
(5) Lower Link
(6) Draw Bar
