(1) Seat Adjustment Lever
To adjust the seat position, pull the
lever (1) to left under the front of the
seat, slide the seat to the desired po-
sition, and then release the lever.
Make sure that the seat is rmly xed
by moving it gently after adjustment.
SEAT ADJUSTMENT
SEAT SLIDING
Do not put a hand between the
seat and the slides when ad-
justing the seat position. You
can get injured unexpectedly.
CAUTION
H61O429A
To change the seatback angle, raise
the lever (1) on the left of the seat.
Then, adjust the seatback angle with
the lever pulled. Release the lever
after adjustment. Make sure that the
lever is returned and the seat is rm-
ly xed after adjustment.
SEATBACK RECLINING
(1) Seatback Adjustment Lever
(1) Seat Belt
H61O431A
The seat belt is self-retracting type.
Make sure to fasten the seat belt be-
fore driving.
SEAT BELT
H61O430A
