ADDITIONAL WEIGHT (OPTION)
ADDITIONAL FRONT WEIGHT
H11O4D4A
(1) Additional Front Weight
(1) Front Weight Bracket
(2) Spring Washer
(3) Bolt
(4) Nut
(5) Balance Weight
(6) Bolt
(7) Spring Washer
(8) Nut
(9) Front Weight Bolt
(10 ) Nut
(11) Spring Washer
(12) Plain Washer
H61O437A
COMPONENTS FOR ADDITIONAL
FRONT WEIGHT
If the loader is not installed, attach a
weight to the front frame of the trac-
tor as a safety measure.
If a heavy implement is installed at
the rear or when towing a heavy trail-
er, the front wheels may be lifted.
Add sufcient weight to keep steer-
ability and to prevent rollover.
If sufficient weight, such as front
loader, is applied to the front wheels,
remove the extra front weight.
If the front tires are excessively load-
ed, it becomes hard to steer the trac-
tor, the tires can be worn faster and
the durability of the front axle can be
deteriorated.
