1. Make sure to latch the left and
right brake pedals as shown in the
gure while driving on a road.
The
tractor can roll over if depress-
ing only one brake pedal at a high
speed.
Make sure to i nterlock the
brake pedals as an accident,
such as rollover or impact, can
occur during driving, on the
road at high speed.
Do not use sharp-turn-brake
at high speed even in the work
eld. Otherwise the tractor can
be rolled over.
WARNING
BRAKE PEDAL
H61O423A
(1) Brake Pedal (L) (3) Pedal Interlock
(2) Brake Pedal (R)
(A) Lock (B) Unlock
2. To make a sharp turn in a work
eld, disengage the left and right
brake pedals to use one of brake
pedals separately. Unlock the
brake lock, and then turn the
steering wheel while depress-
ing the brake pedal on the turning
side.
PARKING BRAKE LEVER
(1) Parking Brake Lever (3) Pedal Interlock
(2) Brake Pedals
(A) Depressing (B) Pressing Down
H61O424A
AU
To stop the tractor, depress the brake
pedal and pull the lever up to apply
the parking brake.
