4-26
n
KitchenAid 2013 Stainless Steel Tall Tub Dishwasher
COMPONENT ACCESS
3. Remove motor from seal, see gure 4. 5. Remove seal, see gure 6.
4. Pry up on old seal, see gure 5.
Figure 4
Figure 5
Figure 6
6
4
5
Steps for Removing Old Wash Motor (continued)
