COMPACT AHU WITH HEAT RECOVERY EVO-T +
OPERATION AND MAINTENANCE MANUAL
114
DEC Address
Variable name Description States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
226 452 F_Re3 Forcing relay output 3 0 – no forcing, 1 – forcing o, 3 – forcing on MSV Register R/W
227 454 F_Re4 Forcing relay output 4 0 – no forcing, 1 – forcing o, 3 – forcing on MSV Register R/W
228 456 F_Re5 Forcing relay output 5 0 – no forcing, 1 – forcing o, 3 – forcing on MSV Register R/W
229 458 F_Do1 Forcing of the digital output 24VDC Do1 0 – no forcing, 1 – forcing o, 3 – forcing on MSV Register R/W
230 460 F_Do2 Forcing of the digital output 24VDC Do2 0 – no forcing, 1 – forcing o, 3 – forcing on MSV Register R/W
231 462 FoAout1 Forcing analogue output 1 0 – inactive, 1 – active MSV 7392 R/W
232 464 F_Aout1 Value in the forcing mode of analogue output 1 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
233 466 FoAout2 Forcing analogue output 2 0 – inactive, 1 – active MSV 7456 R/W
234 468 F_Aout2 Value in the forcing mode of analogue output 2 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
235 470 FoAout3 Forcing analogue output 3 0 – inactive, 1 – active MSV 7520 R/W
236 472 F_Aout3 Value in the forcing mode of analogue output 3 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
237 474 FoAout4 Forcing analogue output 4 0 – inactive, 1 – active MSV 7584 R/W
238 476 F_Aout4 Value in the forcing mode of analogue output 4 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
239 478 HPen Pre-heating function 0 – inactive, 1 – active MSV 7648 R/W
240 480 RecEN Recovery function 0: Inactive, 1: KCO, 2: KCX MSV Register R/W
241 482 HSen Secondary heating function 0 – inactive, 1 – active MSV 7712 R/W
242 484 Cen Cooling function 0 – inactive, 1 – active MSV 7744 R/W
243 486 SKen Sauna / replace function 0 – inactive, 1 – active MSV 7776 R/W
244 488 PasImpuls Active password time 1min = 256 (22min = 22*256 = 5632 = 0x1600) AV Register R/W
245 490 Rest2 Resetting the advanced settings to the factory settings 0 – inactive, 1 – active MSV 7840 R/W
246 492 Rest1
Resetting the main menu and user settings to factory
defaults
0 – inactive, 1 – active MSV 7872 R/W
247 494 TsetActual Req. temp. 1°C = 256 (22 °C = 22*25 6 = 5632 = 0x1600) AV Register R
248 496 Tmain Master temp. 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
249 498 B3 External temp. 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
250 500 PwrSup Air supply fan 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R
251 502 PwrExh Air exhaust fan 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R
252 504 MainS Lead sensor 1: HMI, 2: Intake, 3: Outlet, 4: PT5 MSV Register R
253 506 Work System operation conrmation 0 – stop, 1 – start MSV 8096 R
Alarms
254 508 ResAl Deletion of blocking alarms 0 – no deletion, 1 – deletion BV 8128 R/W
255 510 A_AF Fire alarm 0 – no alarm, 1 alarm present BV 8160 R
256 512 A_LowTemp Low intake temperature alarm 0 – no alarm, 1 alarm present BV 8192 R
