11.3 The main screen.
The parameters of the text menu that can be changed are
marked in green (in the monochrome OMM version italics
with underlining).
Table 10
Date
06-03-19
Current date (can be set in Main
menu/Settings/Date/Language)
Time
08:50:55
Current time (can be set in Main
menu/Settings/Date/Language)
System status
Stop
Current system condition,
available conditions:
- Current system condition,
available
- Operation at speed 1, 2, 3 –
system is operating, fans are
working at selected speed,
depending on Eco, Comfort
and Max operating modes
- Stop-fault – system stopped
by an alarm blocking opera-
tion
- Heating up
Select the mode of
operation
Stop
System operating mode setting:
Stop – system is stopped
Eco – system start with reduced
air supply/exhaust fans output
and low requested temperature,
recommended for night operation
Comfort – system start with
optimal air supply/exhaust fans
output and optimal requested
temperature, recommended
for operation during standard
room usage
Maximum – system start with
maximum air supply/exhaust fans
output and increased requested
temperature, recommended
during intensive room usage or in
order to ventilate room quickly
Calendar – system start in
line with
timer settings
Req. temp.
correction
+1°C
Correction of current requested
temperature (±3°C)[K], this
option is also active during
operation with the timer
Main menu – >
User settings menu (see detailed
description in section
“Main menu”)
Req. temp.
...°C
Current setting of requested
temperature (total of requested
value related to operation mode
and correction of the requested
value)
Master temp.
...°C
Current value of master
temperature
External temp.
...°C
Current value of external
temperature
Air supply fan
...%
Current control level of air
supply fan
Air exhaust fan
...%
Current control level of air
exhaust fan
Master sensor
Nawiew
Readout of currently selected
master temperature sensor
11.4 User main menu
11.4.1 Operation mode
Table 11
The submenu enables setting the output of air supply and exhaust fans and
setting temperature for the eco mode
Eko ->
Air supply – control level setting
of air supply fan
Air exhaust – control level
setting of air exhaust fan
Pressure setting – requested
pressure setting (active in case
of output adjustment of pressure
transducer)
Temperature setting –
requested temperature setting
