COMPACT AHU WITH HEAT RECOVERY EVO-T +
OPERATION AND MAINTENANCE MANUAL
72
Fig. 1 The compact EVO-T+ 8000 (bottom view for the suspended version / top view for the horizontal version).
Fig. 2 Compact air handling unit EVO-T+ 5000; EVO-T+3000 (bottom view).
