70
AUTOMATION AND CONTROLLER FOR UNITS EVO-T; EVO-T COMPACT
OPERATION AND MAINTENANCE MANUAL
Table no. 16 Variables of Settings Menu
DEC address
Variable
name
Description / Variables Settings Menu States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
71 142 Ch_Tmain Selection of the lead sensor
1 - HMI CON, 2 - HMI RS485, 4 - Supply, 8 - Exhaust,
16 - PT5, 32 - Auto
MSV Register R/W
72 144 EcoDi ECO temp. dierence 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
73 146 StartTime Setpoint temperature start ramp and cascade controller activation delay 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
74 148 TsetCor Setpoint temperature correction (start ramp) 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
75 150 Season Season selection 0 - Auto, 1 - Winter, 2 - Sum-mer MSV Register R/W
76 152 Tsummer Outdoor temperature above which the system operates in Summer mode 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
77 154 HistSum Hysteresis of the sum-mer/winter temperature threshold 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
78 156 TsetStd Standby temperature setting 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
79 158 Ch_Tstd Selection of the lead sensor in the stand-by mode 1 - HMI CON, 2 - HMI RS485, 4 - Exhaust, 8 - PT5 MSV Register R/W
80 160 TstdbyAct Current temperature of the lead sensor in stand-by mode 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
81 162 StdMode Stand-by mode activation for: 1 - heating, 2 - cooling, 3 - heating and cooling MSV Register R/W
82 164 StdHis Standby temperature setting 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
83 166 v1_t Delay of the fans' switch-on in relation to the dampers 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
84 168 DelThr Delayed of the dampers shutdown 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
85 170 PresDel Delay in testing the status of pressure switches and lters 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
86 172 CoolingTime
Cooling time of the electric heater, gas heater, freon cooler and/or HPM/
CM module
1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
87 174 SupCooling Supply airow rate - cooling 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
88 176 ExhCooling Exhaust airow rate - cooling 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
89 178 Kp_CP Constant fan airow control-ler amplication 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
90 180 Ti_CP Integration constant of fan constant airow rate control-ler 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
91 182 PaSZ1 Setpoint pressure of 1 gear for supply constant airow rate 1pa = 256 (22pa = 22*256 = 5632 = 0x1600) AV Register R/W
92 184 PaSZ2 Setpoint pressure of 2 gear for supply constant airow rate 1pa = 256 (22pa = 22*256 = 5632 = 0x1600) AV Register R/W
93 186 PaSZ3 Setpoint pressure of 3 gear for supply constant airow rate 1pa = 256 (22pa = 22*256 = 5632 = 0x1600) AV Register R/W
94 188
DPTrange-
Sup
Measuring range of the supply pressure sensor (set according to the setting
on the sensor)
1pa = 256 (22pa = 22*256 = 5632 = 0x1600) AV Register R/W
95 190 FlowSZ1
Setpoint airow rate in 1 gear for constant supply airow (converted from
pressure and K factor)
1m3/h =256(22m3/h=22*256=5632=0x1600) AV Register R
96 192 FlowSZ2
Setpoint airow rate in 2 gear for constant airow (convert-ed from
pressure and K factor)
1m3/h = 256 (22m3/h = 22*256 = 5632 = 0x1600) AV Register R
97 194 FlowSZ3
Setpoint airow rate in 3 gear for constant supply airow (converted from
pressure and K factor)
1m3/h = 256 (22m3/h = 22*256 = 5632 = 0x1600) AV Register R
98 196 Ksup K factor for conversion of pressure into supply air ow 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
99 198
VentSupQu-
-ant
Number of supply fans (calculated cumulative air-ow and measurement
of all the supply fans)
1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
100 200 PaEZ1 Setpoint pressure of 1 gear for exhaust constant airow rate 1pa = 256 (22pa = 22*256 = 5632 = 0x1600) AV Register R/W
101 202 PaEZ2 Setpoint pressure of 2 gear for exhaust constant airow rate 1pa = 256 (22pa = 22*256 = 5632 = 0x1600) AV Register R/W
102 204 PaEZ3 Setpoint pressure of 3 gear for exhaust constant airow rate 1pa = 256 (22pa = 22*256 = 5632 = 0x1600) AV Register R/W
103 206 DPTrangeExh
Measuring range of the exhaust pressure sensor (set according to the setting
on the sensor)
1pa = 256 (22pa = 22*256 = 5632 = 0x1600) AV Register R/W
104 208 FlowEZ1
Setpoint airow rate in 1 gear for constant exhaust airow (converted from
pressure and K factor)
1m3/h = 256(22m3/h=22*256=5632=0x1600) AV Register R
