71
DEC address
Variable
name
Description / Variables Settings Menu States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
105 210 FlowEZ2
Setpoint airow rate in 2 gear for constant exhaust airow (converted from
pressure and K factor)
1m3/h=256(22m3/h=22*256 = 5632=0x1600) AV Register R
106 212 FlowEZ3
Setpoint airow rate in 3 gear for constant exhaust airow (converted from
pressure and K factor)
1m3/h = 256(22m3/h=22*256=5632=0x1600) AV Register R
107 214 Kexh K factor for conversion of pressure into exhaust air ow 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
108 216
VentExhQu-
-ant
Number of exhaust fans (calculated cumulative set-up and measurement
ow of all exhaust fans)
1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
109 218 Sup1 Minimum supply airow rate 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
110 220 Sup2 Average supply airow rate 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
111 222 Sup3 Maximum supply airow rate 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
112 224 RSsup RS485 supply inverter 0 - inactive, 1 - active MSV Register R/W
113 226 RSsup2 RS485 supply inverter 2 0 - inactive, 1 - active MSV Register R/W
114 228 AdrSup RS485 supply inverter 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
115 230 AdrSup2 RS485 supply inverter 2 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
116 232 Exh1 Minimum exhaust airow rate 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
117 234 Exh2 Average exhaust airow rate 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
118 236 Exh3 Maximum exhaust airow rate 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
119 238 Rsexh RS485 Exhaust inverter 0 - inactive, 1 - active MSV
Coil 3808
R/W
120 240 RSexh2 RS485 Exhaust inverter 2 0 - inactive, 1 - active MSV
Coil 3840
R/W
121 242 AdrExh RS485 Exhaust inverter 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
122 244 AdrExh2 RS485 Exhaust inverter 2 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
123 246 TaccVent Inverter acceleration time 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
124 248 TdecVent Inverter stopping time 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
125 250 RECproc Participation in cross recovery temperature con-trol 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
126 252 FXproc Contribution to the temper-ature control of the re-versible aggregate 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
127 254 MIXproc Participation in mixing chamber temperature con-trol 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
128 256 h_c_proc Participation in heat-er/cooler temperature con-trol 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R
129 258 Kp_Heat Temperature controller amplication - heating 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
130 260 Ti_Heat Integration constant of temperature controller - heating 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
131 262 Kp_Cool Temperature controller amplication - Cooling 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
132 264 Ti_Cool Integration constant of temperature controller - Cooling 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
133 266 PIcoolingAct Cooling PI 0 - Summer , 1 - Summer/Winter MSV
Coil 4256
R/W
134 268 DelOnPIcool Delayed start of cooling PI 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
135 270 Kp_Blow Minimum and maximum supply temperature controller amplication 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
136 272 Ti_Blow
Integration constant of minimum and maximum supply temperature con-
troller
1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
137 274 TminBlow Minimum supply temperature 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
138 276 TmaxBlow Maximum supply temperature 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
139 278 TsetBlowAct Current supply temperature setpoint for type "2" controller 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
140 280 RecDown Recovery Start Ramp 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
141 282 TlimRec Minimum permitted exhaust temperature behind recovery (frosting) 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
142 284 RecDeltaT
Required dierence between exhaust and outside temperature for recovery
start
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
